Pigment Red 53: 1-Corimax Red CNS

Technical parameters of Pigment Red 53:1

Fargeindeks nr.Pigment Red 53: 1
ProduktnavnCorimax Red CNS
ProduktkategoriOrganisk pigment
Lysstyrke (belegg)3
Varmebestandighet (belegg)180
Lysstyrke (plast)4
Varmemotstand (plast)240
Farge
Tonefordeling

Bruksområde : Pigment Red 53: 1 har lav viskositet.
Anbefales for pulverlakk, PVC, gummi, PP, PS, PE, forskyvningsblekk, vannbasert blekk, løsemiddelblekk.
Foreslått for PU, UV-blekk.

TDS(Pigment-Red-53:1) MSDS(Pigment Red 53:1)

Relatert informasjon

Pigment name: C.I.Pigment Red 53: 1 (C.I.Pigment Red 53: 1; P.R.53: 1)
Alias: Lake Red C (barium salt); Red Lake C (barium)
Chemical name: 5-chloro-2-[(2-hydroxy-1-naphthalenyl) azo] -4-methyl-Benzenesulfonic acid, barium salt (2: 1)
Molecular formula: C34H24Cl2N4O8S2Ba
Molecular weight: 888.98
CAS No: 5160-02-1

Molekylær struktur:
Physical and chemical properties: Solubility: dark brown in potassium hydroxide alcohol solution; red precipitation in aqueous solution plus hydrochloric acid; cherry red in concentrated sulfuric acid, brown red precipitate after dilution; slightly soluble in hot sodium hydroxide (yellow), slightly soluble It is insoluble in benzene and acetone in ethanol and water. Hue or light: brilliant yellow light red relative density: 1.65-2.11 bulk density / (lb / gal): 13.7-17.5 melting point / ℃: 380-390 average particle size / μm: 0.07-0.5 particle shape: needle-like, rod-like specific surface area (m2 / g): 7-110 pH value / (10% slurry): 6.5-8.0 Oil absorption / (g / 100g): 40-78 Hiding power: translucent

Produktbruk: This pigment is more yellow than Pigment rød 57: 1, called Warm Red, has high tinting strength and vividness, and is sensitive to acid / alkali. Used in printing inks, good solvent resistance and heat stability (200 ° C / 10min); used in water-based flexographic inks, molecular metal and base ink alkali agent to reduce stability; used in rubber and plastics, in HDPE Medium heat resistance 260 ℃ / 5min, can be used for food, cosmetics and medicine coloring. There are more than 130 brands on the market.

Syntetisk prinsipp: CLT-acid is added to an aqueous solution of hydrochloric acid, stirred overnight, cooled down the next day, and diluted. Sodium nitrite solution is added below the liquid surface to diazotize and diluted for future use. , Dilute, add diazonium salt suspension coupling under the liquid, stir, add dilute acetic acid, and filter; stir the obtained paste with water, dilute, and then add dilute acetic acid to make it acidic, add barium chloride boiling solution, and boil Color precipitation, filtration, and drying to obtain the product.
